The MY Series induction bearing heater from China is a professional equipment for heating rolling bearings, which can efficiently heat bearings or other annular metal workpieces. Our induction bearing heater can quickly and efficiently heat the workpiece, which can effectively avoid overheating and damage the bearing structure. There are many models to choose from.
1) Adopt the most advanced chip micro processing technology, strong and durable design for continuous working condition provides a safe and reliable guarantee.
2) Will the microcomputer control technology applied in heating control process, so as to realize the heater soft start, soft stop, automatic adjust the output power, automatic detection procedures, self heating device failure, and abnormal working state diagnosis and protection function.
3) Heating temperature and time can be preset and display, cylindrical peng expansion, the hole is changeless, can become a production line of a processing link, significantly save production cost.
4) Special design in lower consumption provides higher effect, to save energy.
Specifications:
Model | MY-1 | MY-3.6 | MY-8 | MY-12 | MY-24 | MY-40 | MY-100 |
Power (KVA) | 1 | 3.6 | 8 | 12 | 24 | 40 | 95 |
Voltage (V) | 220 | 380 | |||||
Whirling arm | NO | YES | NO | ||||
Max. Bear weight (KG) | 15 | 35 | 125 | 250 | 600 | 1250 | |
Bear inner diameter (mm) | 15-100 | 30-160 30-160 |
50-250 | 70-400 | 85-600 | 85-800 | 145-1200 |
Max. Outside Diameter | 150 | 340/480 340/480 |
480/720 | 700/1020 | 700/1020 | 1400 | 2500 |
Max. Width | 60 | 150 150 |
200 | 265 | 400 | 420 | 700 |
Max. Temperature | 300degree | ||||||
Magnetic probe | YES | ||||||
Tem display | YES | ||||||
Control type | Manual operation / time control / temperature control | ||||||
Time range | 0-99mins | ||||||
Auditory tone cues | YES | ||||||
Time digital display | YES | ||||||
Heat preservation function | YES | ||||||
Auto degauss | YES | ||||||
Dimension (cm) | 32 * 22.5 * 27.5 | 34 * 29 * 38 | 63 * 36.5 * 47 | 95 * 64 * 100 | 100 * 50 * 135 | 150 * 60 * 147 | 230 * 100 * 100 |
Dimension of heat bar | Can be customized by your specific requirements | ||||||
Extended arm | NO | 60 * 60 * 120 | 70 * 70 * 120 | 80 * 80 * 160 | 80 * 110 * 160 | NO | |
Weight without arm | 10KG | 31KG | 53KG | 120KG | 200KG | 660KG | 2350KG |
Support level heat | NO | Either | YES | YES | Either | YES | YES |
Move | NO | YES | Either |
